The introduction of the vacuum concentrator

The equipment mainly consists of six parts: condensing tank, condenser, vapor-liquid separator, second condenser, cooler and liquid receiving barrel. All of them are made of stainless steel. Concentration tank for the jacket structure, the condenser for the tube-type, cooler for the coil tube.surface finish is food grade mirror polished.

The equipment has single effect ,double effect and triple effect 3types external circulation vacuum concentrator .

Feature and advantage of the vacuum concentrator

1. The diversion trench circulative evaporation technology is adopted:
Compared with traditional structure, the evaporation efficiency is increased by about 15%. Meanwhile, it can effectively prevent bubbles from being produced during material evaporation and can avoid foam entrainment.

2. The flat bottom evaporation technology is adopted:
Compared with traditional conical bottom evaporation technology, the equipment structure is more compact and the operation height is greatly reduced so that the dual-effect 3000 concentrator can easily complete observation and operation without the need of using the platform, but the traditional 1000 concentrator can be operated only after the platform is used.

3. The plate type heat exchanger condensing and cooling technology is adopted:
Compared with the original tubular structure, it can achieve a solvent recovery rate of 95% and an increased vacuum diameter. The concentrating temperature does not increase and the equipment has compact structure.

Application of the vacuum concentrator

1) This Single-effect vacuum concentrator equipment is suitable for evaporation and concentration the liquid material and recycling the organic solvent in pharmaceutical, foodstuff and chemical industry, etc.

2) It is specially suitable for low temperature concentration for milk, juice and the majority heat-sensitivity material.

Technology parameter of the vacuum concentrator

Model Items	WZ-300	WZ-500	WZ-1000	WZ-2000	WZ-3000
Evaporation capacity (kg/h)	300	500	1000	2000	3000
Cost steam (kg/h)	330	550	1100	2200	3300
Steam pressure (Mpa)	0.1
Vacuum degree (Mpa)	0.06~0.08
Heat area (m²)	4.5	7	14	28	56
Condenser area (m²)	6	10	20	40	60

If you have different request of evaporation capacity and heat area ,pls inform the information to us ,we can custom made it for you.

Our factory also can produce vacuum evaporator, vacuum extractor,leaf extractor ,evaporator crystallizer,
