Seself cleaning strainer is the high efficiency scraping self-cleaning filter independently developed by KOSUN. Removing the impurities particles on the filter screen external surface by mechanical scraping, it continuously filters on-line.
self cleaning strainer is designed for fine and accurate filtration ranging from 50-500 micron. It can avoids extruding and breaking the impurities and is capable of the filtration for water and liquids of viscosity up to 800000cps.
Features of the self cleaning strainer
1. Automatic 24-hour on-line filtration, no frequent changing out and cleaning
2. No disposable filter media comsuption, save filter media cost and environment cost
3. Stainless steel scraping blade, good impurity removing performance
4. Top quality V-SLOT filter element, accurate slots, extreamly smooth, easy to scrap
5. Very low pressure drop, stable flowrate, save energy comsuption
6.back-flushing function can be added to help clean the filter element
7. Close filtration, no dangerout liquid leakage, good for safe production
8. Discharge waste liquid with high impurity concentration, avoid valuable liquid loss
9. Various modular combination and automation modes available, meet different filtration needs
10.Equiped with world-famous gear motor, high reliablity and long service life
11.Assitant lifting device , only one operator can open and close the filter cover
Filter Models | KS11 | KS22 | KS34 | KS75 | KS100 | KS136 |
Filter Area (m2) | 0.27 | 0.22 | 0.34 | 0.75 | 1.0 | 1.36 |
Volume (L) | 16 | 30 | 50 | 145 | 195 | 320 |
Inlet and Outlet Size | DN40-DN50 | DN50-DN80 | DN50-DN100 | DN65-DN100 | DN80-DN125 | DN100-DN150 |
Drain Size | DN25 | DN40 | DN50 | DN50 | DN50 | DN50 |
Flow rate (m3/h) | 20 | 50 | 150 | 300 | 500 | 1100 |
Cleaning water consumption (L/time) | 80 | 80 | 80 | 150 | 150 | 500 |
Motor Power(kw) | 0.55 | 0.55 | 0.55 | 0.55 | 0.55 | 0.75 |
Applicable Liquid | River water, lake water ,recycle water, process water, reinjection water, sea water, potable water and viscosity liquid |
Filtration Rating | 50-2000um |
Standard Design Pressure | 1.0MPa, high design pressure available |
Design Temperature | 0-250DegC |
Filter Area Per Filter | 0.11m2-1.36m2 |
Cleaning Differential Pressure | 0.05MPa |
Differential Pressure Instrument | differential pressure transmitter(DPT) or differential pressure switch(DPS) |
Gear Motor | 180W, three phase, 380v, protection class IP 55; worm reduction gear |
Inlet and Outlet Standard | Flange(DIN,ISO ,ANSI ) |
Filter Element Type | V-SLOT slotted slotted screen, 316L material |
Housing Wet Part Material | 304/316L/CS |
Scraping Blade Material | 304/316L |
Housing Seal Material | NBR/VITON(FKM) |
Discharging Valve | Pneumatic ballvalve, protection class IP65 |
Supply Facility Requirement | 380V AC, 0.4-0.6MPa clean and dry compressed air |
