Sand Filter Tank

Introduction of the sand filter tank

The designed flow rate of quartz sand filter tank is 8-15 m / h, and the filter contains 4-60 object quartz sand filter material. It can effectively remove suspended matter, particulate matter, mechanical impurity and colloidal impurity in water. Reduce the turbidity of water.

Because the surface filter layer and the filter membrane are destroyed, the filtration efficiency is obviously reduced, so it is advisable to use low velocity operation after backwash. In order to form the filter membrane, the quartz sand filter has reasonable upper and lower water distribution system. Compared with other filters, it has the advantages of more uniform water distribution and stable effluent quality, and ensures the system water flux at the same time.

Technical parameters of the sand filter tank  　

Filtration speed ：8-10m3/h

water turbidity：≤5mg/L； 　　

Operate temperature :ATM

Operate pressure ：≤0.6Mpa; 　　

Back washing compressed air capacity：18-25L/m2.S

Filter media height ：1000-1200mm 　　

Back washing strength：4-12L/m2.S;

Back wash time ：4-6minutes

Applications of the sand filter tank

Mechanical filters are used in many processes, such as the familiar electrodialysis project. One of the processes that must be followed before purifying water is to remove suspended matter through a mechanical filter. There are also many processes such as desalination of brackish water, production of water in space, drinking pure water, defluorination of underground water, preparation of pharmaceutical injections, chemical fertilizers, water for the machinery industry, and so on.
