Y Strainer

Introduction of the Y strainer The Hygienic Y strainer and Y filter is ideal to remove a small amount of solid particles in liquid, Prevent foreign bodies damaging or blocking process equipment, such as flow meters, valves and pumps;When it need to be clean,as long as you Take out the filter...

Send Inquiry

Chat Now

Introduction of the Y strainer

The Hygienic Y strainer and Y filter is ideal to remove a small amount of solid particles in liquid, Prevent foreign bodies damaging or blocking process equipment, such as flow meters, valves and pumps;When it need to be clean,as long as you Take out the filter screen,

This series of filters have advantages for compact structure, high flow ability, small pressure loss, the applicable scope is wide, easy maintenance, price is low and so on.

Y strainer(001).jpg

Parameters of the Y strainer

Material:	Stainless steel 304 and stainless steel316L
Cap seal	EPDM, Silicon ,Viton
Mex working pressure:	10 bar 145 PSI
Pore size	0.5-2.0mm
Filter Screen:	10-500mesh
Connection dimension	DN25-DN100 1"-4"
Connection type :	Clamp/ weld / thread
Availably standard:	DIN/ SMS/ RJT/ IDF/ 3A
Certificate:	3A
Applicationscope:	Dairy,food, beverage, pharmacy, cosmetic, Chemical, etc

Hot Tags: Y strainer, manufacturers, sanitary, stainless steel, food grade
