Introduction of the sterile air filter housing
The sterile are filters are designed for removing of impurities( dirt, dust, and moisture & oil contaminants,etc) from compressed air applications in pharmaceutical, chemical and food industry, biotechnology, breweries, dairies, hospitals and aseptic packaging.
Features of the sterile air gas filter housing
Food grade stainless steel 316L and stainless steel 304
Food grade Mechnical polished Ra<0.4um and industrial grade sand blasting
Available of single round air gas filter and multi gas filter housing 3round ,5round ,7round to 12rounds
The body closure could be ferrule clamp or flange type
The filter adaptor is code7 ,222 and DOE type
Filter length from 5inch to 40inch
Application of the sterile gas air filter housing
Gas filtration
Sterile air filtration
Fermentation gas filtration
Compressed gas filtration
Air sterile filter for bacterials filtration in Cell and tissue culture media and Intermediates
Filters for liquids and air filter in Vaccines , Ophthamics and SVP and LVP processing industry
PTFE air vent filter tank to keep air clean enough for the industry processing system include bioreactors, autoclaves, freeze dryers and process tanks, etc.
Air filter Cartridges | Body Closure |
| Dimensions(mm) | ||||
Nos. | Length | Inlet/outlet size | Outlet/ | Diameter | Bottom | Height | |
1 | 5" | Ferrule clamp,Flange | 3/4 inch | Tri Clamp | 102 | 180 | 340 |
10" | 1 inch | 450 | |||||
20" | 1 inch | 690 | |||||
30" | 1 1/4 inch | 940 | |||||
3 | 10" | Flange, Stud bolts | 2 inch | Flange | 184 | 325 | 755 |
20" | 2.5 inch | 995 | |||||
5 | 10" | 3 inch | Flange | 219 | 380 | 880 | |
20" | 4 inch | 1180 | |||||
