Introduction of powder Sintered filter cartridge

The sintered filter cartridge is made of stainless steel power ,through the sub-screen, forming, sintering to micro-filter components. According to user requirements can produce a variety of shapes, structure, different size, porosity of porous components, such as: hood, cap, sheet, tube, rod-like filter element.

Specification of powder Sintered filter cartridge

stainless steel powder sintered filter cartridge		stainless steel powder sintered filter plate
Diameter:	Ф20mm -Ф200mm	Diameter:	Ф5mm-Ф300mm
Length:	L50-L1200 (can be customized on request)	Thickness:	0.5mm-10mm
Thickness:	2mm or more	Pore size:	0.5um-70um
Pore size	0.5um-70um	Material:	Stainless steel
Porosity	20-50%	Porosity	20-50%
Permeability	3-1300m3 / m3hkPa	Permeability	3-1300m3 / m3hkPa
Temperature resistance	500 Deg C	Temperature resistance	500 Deg C
Maximum working pressure	0.6Mpa	Maximum working pressure	0.6Mpa

Application of powder Sintered filter cartridge

The stainless steel powder sintered filter element can be widely used in the pharmaceutical industry, water treatment industry, food industry, biological engineering, chemical industry, petrochemical industry, metallurgy industry and gas purification field.

Typical uses include:

1, chemical raw materials in the production process in addition to impurities filter, the material decarburization filtration and fine filtration.

2, water treatment of ultrafiltration, RO, EDI system, security filtering.

3, food and beverage drinks, fruit juice, liquor, beer, vegetable oil, mineral water, soy sauce, vinegar clarification filter.

4, chemical industry liquid products, liquid raw materials, pharmaceutical intermediates decarbonization filtration and precision filtration, ultra-fine crystals, the catalyst filter recovery, resin adsorption after the precision filter and the system heat conduction oil, material removal filter, catalytic gas Purification and so on.

5, oilfield water filtration and other areas of reverse osmosis security filtering.

6, the dye industry, high-temperature decarbonization, bleaching disabilities filter.

7, gas purification of the vapor, compressed air, catalyst filtration.

8, Pneumatic components, lubricants, fuel and hydraulic pressure system, media purification and flow restrictions, compressed air degreasing purification, crude oil desanding filtration, nitrogen and hydrogen gas filtration, pure oxygen filtration, bubble generator, floating bed gas distribution
