Introduction of the air filter cartridge
This PTFE filter is made of hydrophobic polytetrafluoroethylene(PTFE) membrane with excellent retention characteristics, flow rates.
It offers a wide range of chemical compatibility with high thermal stability, specially used for the filtration of compressed air/gas, vent air and aggressive chemical solutions including acids, alkalis, solvents, photoresists, etc.
Features of the air filter cartridge
1. Naturally hydrophobic PTFE membrane with excellent porosity, high flow rate;
2. Absolute rating, filtration efficiency≥99.99%, Up to 0.01 micron in gas sterile filtration;
3. Low pressure drop and long service life;
4. Wide chemical compatibility, resistant to strong alkali, acids, aggressive gases and solvents;
5. High temperature endurance performance;
6. 100% integrity tested before final assembly;
Application of the air filter cartridge
Compressed air, CO2 line sterile filtration;
Tank vent, Fermentation air;
Aggressive acids, Bases, Solvents;
Photoresists, Etch Solutions;
Parameters of the air filter cartridge
Materials Of Construction | Filter Media: | Hydrophobic PTFE membrane |
Support Layers: | PP | |
Micron Rating: | 0.1, 0.2 um | |
Cage, Core, End caps: | Polypropylene | |
Seal Method: | Thermal Bonded, No Adhesives | |
O-rings/Gaskets: | Silicone, Nitrile, EPDM, Viton, Teflon | |
Cartridge Dimensions | Outer Diameter | 69mm |
Inner Diameter | 33mm | |
Length | 5, 10, 20, 30, 40 Inch | |
Filtration Area(m2) | 0.65 m2 per 10'' | |
Operating Conditions | Normal Operating Temp: | Up to 65℃ (140℉) |
Max.Operating Temp: | 90℃ (194℉) at P≤1.0 bar (14.5psi) | |
Max. Differential Pressure | ||
Normal Flow: | 4.2 bar (60 psi) at 25℃ (77℉) | |
Reverse Flow: | 2.1 bar (30psi) at 25℃ (77℉). | |
PH Value compatibility: | 1-14 | |
Sterilization: | Steam Sterilization for 30 minutes at 121±2 ℃, 100 cycles, Autoclave 30minutes (optional) |
