The Activated Carbon Vessels like a sand filter is used as a basic sediment filter, removing large particles from water such as dirt, sand, mud, rust and other large sediment, however the granulated Activated carbon also absorbs chlorine and organic molecules from the water making it smell and taste better.
Active carbon material is nutshell carbon,it is light weight,big holes,strong abrasion resistance and strong absorption,the filling height is:
Activated carbon material: 0.6-1.2mm 1100mm, ---top layer
Quartz sand material: 0.6-1.2mm 100mm,---middle layer
Quartz sand material: 1.2-2.0mm 100mm,----bottom layer
Carbon filtration has great capabilities in industry, breweries, waterworks, and wastewater treatment. Kosun's activated carbon filter vessel is made of 304 stainless steel 316SS as an option, working pressure of the activated carbon filter vessel from 4 bar to 6 bar.
Features of the activated carbon filter
The materials for the tank are: stainless steel, steel lined with rubber .
The surface finish can be matt polished or acid washing or mirror polished
The design pressure can be 10 bar g
Application of the activated carbon filter
As the mechanical filter ,it is mainly used for removal of organism, colloidal silicon, remained chlorine etc. It has higher absorption ability to odor, color and heavy metal molecular.
The carbon chosen for mineral water, purify water and beverage industry is water-purify carbon which can enhance the taste of pure water.
It can be used as the pretreatment system for RO, electro dialysis, and ion exchange system that can safeguard these equipment
Activated carbon filter can back flush timely and also can be showered by NaOH,HCL. If condition allowed, it also can be washed by vapor blower which should be remarked before ordering, so that we can design and produce accordingly.
Parameter
|
MODEL |
CAPACITY(M3/H) |
FILTERING SPEED |
HEIGHT OF FILTER MEDIA LAYER |
DIMENSION(MM) |
DIA. OF OUTLET AND INLET |
|
ACT-1 |
1 |
10-20 |
600-800 |
DN300×1500 |
DN20 |
|
ACT-3 |
3 |
700-900 |
DN500×2000 |
DN25 |
|
|
ACT-5 |
5 |
800-1000 |
DN700×2400 |
DN32 |
|
|
ACT-8 |
8 |
1000-1200 |
DN900×2800 |
DN40 |
|
|
ACT-10 |
10 |
1100-1300 |
DN1000×2800 |
DN40 |
|
|
ACT-15 |
15 |
1100-1300 |
DN1200×3000 |
DN50 |
|
|
ACT-20 |
20 |
1100-1300 |
DN1400×3000 |
DN65 |
|
|
ACT-30 |
30 |
1100-1300 |
DN1800×3200 |
DN80 |
|
|
ACT-40 |
40 |
1100-1300 |
DN2000×3200 |
DN100 |
