Self Cleaning Filter

Introduction of the self cleaning filter

As the automatic self cleaning filter , it can automatically removes particles from the filter element surface by the mechanical scraping, and it can work on-line continuously, this kind self cleaning is capable of both low viscosity liquid and high viscous liquids.
The motor drives the scraper to rotate and remove the particles on the filter element internal surface.

The conventional manual filter gets frequently clogged when filtering viscous liquid or removing viscous contaminant. so that customer has to accept the larger filter and clean the filter frequently. It takes expensive investment, requires hard maintenance and discharges lot of waste liquid. Self cleaning filter is the ideal solution for such problems, always keep the filter element cleaning, and discharges the liquid with high solid content and result in less valuable liquid loss. With its obvious advantage, self cleaning filter is taking the places of conventional ones such as the vibrating screens, bag filters, basket filters and some back-flushing filters, etc..

Features of the automatic self cleaning filter

Filter element:sedge wire type , perforated plate type

Filter rate : 50micron -500micron

Viscosity:1-80000cps

Operate pressure: 6barg ,10 barg ,15 barg ,20 barg

Material:SS304 ,SS316L

Operate temp:0-200 DegC

Cleaning start type: Set Time or Set pressure drop data

Application of the self cleaning filter

water treatment, pulp and paper, petro-chemical, biopharmaceutical,
coatings, inks, oil refinary, food and beverage groundwater, seawater, freshwater, reservoir water, pond water, cooling circulating water, freezing water, high and low spraying water, squirt water, heat exchanging water, sealing water, bearing cooling water, oil wells injection water, recycled process water, machining coolant, cleaning agents, cleaning water,wax, coal oil, monomer, polyer, water, citric acid, fermentation broth, protein, soap, wet end additive, coating, ink, adhesive, rubber, ethanol, chocolate, confectionary, juice, coolant, etc.
